I found this painting online.  It was first published in the National Park Service publication New Discoveries at Jamestown: Site of the First Successful English Settlement in America.  The painting is artist, Sydney King’s  interpretation of the lumber industry in colonial Jamestown.  I find the painting fascinating as it focuses on so many aspects of woodworking.

Lumber production in colonial Jamestown

From a woodworking perspective it covers:

Hewing a log with an adze

Hewing – showing a person using an adze to turn logs into square beams.  Laying next to the log appears to be broad axe and a cant hook used to roll the log.

Pit sawing the beams into boards.

Pit Sawing – Using a large rip saw on a frame (though many were not on frames) to saw the hewn log into planks.  Notice the large brimmed hat on the pitt-man, likely to help him avoid the sawdust.

Crosscutting using a whip-saw

Crosscutting Timber – Using a two-man crosscut saw (also called a whip saw).  The wood was secured on saw horses and cut to length.

Riving wood into planks using a froe and club.

Riving – Straight grained wood (abundant in the old growth forests) could be rived with a froe and club and literally split into planks.

Portable grindstone could be wheeled to where it was needed.

Grinding – The bladed tools at use would need to be re-sharpened.   This particular grindstone was made to be portable, so time would not be wasted running back and forth when sharpening an axe, adze or froe.

Woodshop on site.

Woodshop – It makes sense that the woodshop would be kept as close as possible to the lumber mill (though it may just have been done by the artist to show where wood might have been headed.  This shop seems to contain a great wheel lathe, hatchets, a drawknife, frame saw, several adzes, planes, chisels, and a what I believe is a large jointer sitting on the floor just behind the post on the right.

A fun little glimpse at early American woodworking history.
